技术参数
|
铣型电机功率Pre Milling motor power |
7.5kw*4 |
|
齐头电机功率End trimming motor power |
0.5kw*2 |
|
粗修电机功率Rough trimming motor power |
0.75Kw*2 |
|
精修电机功率Fine trimming motor power |
0.75Kw*4 |
|
机器总功率Total power |
20.5KW |
|
减速机功率 Asynchronous motor power |
5.5Kw |
|
母口铣型主轴直径L tongue milling spindle diameter |
φ 30mm*2 |
|
主轴转数Spindle speed |
9000r / min |
|
导轨宽度Guide width |
80 mm |
|
压料轮长度Press wheel length |
1200mm |
|
子母口压贴成型L shape molding pressing |
可调（气动一键转换，一套成型模。） |
|
辅助加热Auxiliary heating |
二套辅助加热使封边条二次加温贴服更牢固 |
|
机器总功率Total power |
20.5kw |
|
封边带厚度Edge band thickness |
0.4—0.7mm |
|
封边带宽度Edge band width |
10-120mm |
|
板料厚度 Board thickness |
30-60mm |
|
板材最小加工宽度Min width of the wood |
≥120mm |
|
板材最小加工长度Min length of the wood |
≥160mm |
|
进料速度Feeding speed |
0-16m/min |
|
铣型刀可调Adjustable milling cutter |
高低、宽窄，无跳刀现象，换刀方式简易，封平面带预铣刀，产品铣面光洁、平整、直线度≤±0.1mm/2m |
|
胶箱温度Glue box temperature |
可调不小于200度 |
|
工作气压Air pressure |
0.6Mpa |
|
电压Voltage |
380V/50HZ 3Phase |
|
机器重量Total weight |
4000KG |
|
外形尺寸Overall size |
11000mm*1000mm*1950mm |
